ZB-Box3 – Smart Multimode Gateway Hub | Zigbee 3.0 + Bluetooth Mesh + WiFi
Description
Description
Centralized Smart Lighting Control for MiBoxer Zigbee and Bluetooth Devices
The ZB-Box3 is an upgraded smart home gateway hub that supports Zigbee 3.0, Bluetooth Mesh, and WiFi protocols in a single device. It enables seamless control and integration of MiBoxer’s expanding range of Zigbee and Bluetooth-compatible LED lighting products. Designed for large-scale smart environments, the ZB-Box3 can manage up to 128 sub-devices and offers app-based control, voice control, and online firmware upgrades.
This compact powerhouse is ideal for residential, commercial, and marine applications where centralized and responsive lighting control is essential.
💡 Key Features
✅ 3-in-1 Protocols – Supports Zigbee 3.0, Bluetooth 5.0 Mesh, and WiFi for maximum compatibility
✅ Control Up to 128 Devices – Ideal for large smart lighting environments
✅ App Control – Use the Tuya/Smart Life or MiBoxer app to control all connected devices
✅ Third-Party Voice Control – Works with Alexa, Google Assistant, and other smart platforms
✅ Reliable Connectivity – 30m indoor / 100m outdoor range ensures strong signal
✅ Online Upgrades – Stay future-proof with remote firmware updates
📊 Technical Specifications
| Feature | Specification |
|---|---|
| Model Number | ZB-Box3 |
| Input Power | DC5V / 1A (Type-C) |
| Communication Support | Zigbee 3.0 + Bluetooth Mesh + WiFi |
| Wi-Fi Standard | IEEE 802.11 b/g/n 2.4GHz |
| Zigbee Standard | IEEE 802.15.4 |
| Bluetooth Standard | Bluetooth 5.0 |
| Indoor Control Distance | Up to 30m |
| Outdoor Control Distance | Up to 100m |
| Total Sub-Device Capacity | 128 devices (BLE/Zigbee) |
| Simultaneous BLE Connections | 3 devices |
| Working Temperature | -10°C to 40°C |
🛡️ Warranty
2-Year Manufacturer Warranty
