Lumishore- ORA TIX204 Interchangeable Thru-Hull Light

Lumishore – ORA TIX204 Interchangeable Thru-Hull Underwater LED Light – White / Blue / Green

Powerful Precision Lighting in a Compact Marine-Grade Design

The Lumishore ORA TIX204 delivers bright, focused underwater lighting in a sleek, low-profile form. With 5,300 verified fixture lumens and a 60° beam angle, this compact thru-hull light is perfect for transoms, side hulls, or bottom mounts. It’s available in white, blue, or green to match your preferred look and function.

Whether you're lighting up the dock or adding flair to your wake, the TIX204 offers serious performance in a small, easy-to-service package.

• Why It Stands Out

  • Single-Color Precision
    Choose from vivid blue, crisp white, or vibrant green—each with high-intensity output.

  • Focused Beam for Better Impact
    The 60° beam creates a clean spotlight-style wash for added visibility and aesthetics.

  • Compact and Serviceable
    Interchangeable design allows for internal access to the LED and driver without hauling out the boat.

  • Simple Control
    No complex wiring—just connect to a standard ON/OFF switch.

  Key Features


  ✅ 5,300 verified fixture lumens
  ✅ 60° focused beam angle
  ✅ Internal LED array and integrated driver
  ✅ Interchangeable thru-hull design
  ✅ Available in white, blue, or green
  ✅ Compact and low-profile
  ✅ Marine-grade aluminum bronze housing
  ✅ IP68 waterproof rating
  ✅ 3-year Lumishore warranty

  Perfect For

  • Boats 20-45 ft seeking clean and concentrated underwater lighting

  • Owners looking for a simple ON/OFF installation

  • Transom, side, or bottom hull lighting setups

  • Wake illumination, dock presence, and enhanced underwater visibility

  Technical Specifications

  Feature	Specification
  Available LED Colors	Blue, White, Green
  Verified Fixture Lumens	5,300 (White)
  Total Lumens	11,925
  Beam Angle	60°
  LED Configuration	White: 11 x 10W / Blue & Green: 22 x 3W
  LED Life	50,000+ Hours
  Voltage	12/24V DC (AC optional)
  Max Current Draw (12/24V)	4.0A / 1.9A
  Mounting	Thru-Hull, Interchangeable
  Housing Material	Marine-Grade Aluminum Bronze
  Lens	Borosilicate Glass
  Driver	Multi-Channel Internal Driver
  Control	Standard ON/OFF Switch
  IP Rating	IP68
  Warranty	3 Years



  Ready to Add a Clean, Focused Glow to Your Hull?
  The ORA TIX204 gives you everything you need—high output, simple control, and service-friendly design. It's a powerful lighting upgrade in a compact package.
